Julabo FP90 Chiller Circulator Ultra Low

Julabo FP90 Chiller Circulator Ultra Low
Click to enlarge
Price: $21,000.00
Availability: 1
Model: FP90
Average Rating: Not Rated

Description:

Ultra-low Refrigerated Circulator with 2-stage cascade-cooling and proportional cooling control

JULABO Ultra-Low Refrigerated Circulators for heating and cooling are suitable for external temperature tasks. Powerful circulating pump systems and high heating and cooling capacities guarantee short heat-up and cool-down times. ACC ‘Active Cooling Control‘ provides active cooling control across the whole temperature range. An energy saving feature with only minor loss of heat is provided by the proportional cooling capacity control in the ‘FP’ refrigeration units. The inevitable dust accumulation that occurs in refrigeration systems is solved by means of an easily removed venting grill, which allows for easy cleaning. The units are equipped with handles or castors for an easy transportation. All models have a drain tap on the front allowing the fluid to be drained easily. Additionally the instruments are equipped with an improved insulation to help avoid ice-formation, and have a visual liquid level display.

Technical Specifications:

Working temperature range -90 ... 100 °C
Temperature control ICC
Temperature stability ±0.05 °C
Display VFD + LCD
Display resolution 0.01 °C
Integrated programmer available
Heater capacity 3000 W
Cooling capacity
20   0   -20   -40   -60   -80           °C
1800   1700   1600   1350   750   150           W
Refrigerant R404A + R23
Pump capacity Pressure:   10.2 psi
Suction:   5.8 psi
Flow rate: 22-26 lpm
Digital interfaces RS232, RS485, optional Profibus
External Pt100 sensor connection available
Bath opening / bath depth (W x L / D) Ø = 2.7 / 7.9 inches
Filling volume 22 Liters
Dimensions (W x L x H) 23.2 x 29.9 x 45.7 inches
Weight 430 lbs
Ambient temperature 5...40 °C
Classification according to DIN 12876-1 3 (FL)



This unit has been very lightly used and is in excellent condition.  Comes with a 90 Day warranty and has been tested to manufacures Specifications..
